Solar Kit With Battery For Home 3000w 5000w 220V Black Solar Panel 330W All In One Inverter MPPT Pure Sine Wave 80A Farm System

Why choose the hybrid inverter controller instead of solar controller and inverter ?

● Full digital voltage and current double closed loop control, advanced SPWM technology, output of pure sine wave.
● Two output modes: mains bypass and inverter output; uninterrupted power supply.
● Available in 4 charging modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar hybrid charging.
● Advanced MPPT technology with an efficiency of 99.9%.

The importance of hybrid inverter controller UPS

Performance characteristics:

1. Full digital voltage and current double closed loop control, advanced SPWM technology, output of pure sine wave.

2. Two output modes: mains bypass and inverter output; uninterrupted power supply.

3. Available in 4 charging modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar hybrid charging.

4. Advanced MPPT technology with an efficiency of 99.9%.

5. With the charging requirement (voltage, current, mode) settings, and suitable for various types of energy storage batteries.

6. ON/OFF rocker switch for AC output control.

7. Power saving mode available to reduce no-load loss.

8. Intelligent variable speed fan to efficiently dissipate heat and extend system life.

9. Lithium battery activation design, allowing access of lead-acid battery and lithium battery.

10. 360 ° all-round protection with a number of protection functions. Such as overload, short circuit and over current.

11. Supply of a variety of user-friendly communication modules, such as RS485(GPRS, WiFi, Bluetooth), CAN, USB etc., and suitable for computer, mobile phones, Internet monitoring as well as remote operations.

12. Lithium battey can be activated by both mains and PV.

The data ,ideal for 7-10Kw solar panel ,220v off grid system

Models

HF2420S60-100

HF2430S60-100

AC mode

Rated input voltage

220/230Vac

Input voltage range

(170Vac~280Vac) ±2%；(90Vac-280Vac)±2%

Frequency

50Hz/ 60Hz (Auto detection)

Frequency Range

47±0.3Hz ~ 55±0.3Hz (50Hz)/57±0.3Hz ~ 65±0.3Hz (60Hz);

Overload/short circuit protection

Circuit breaker

Efficiency

>95%

Conversion time (bypass and inverter)

10ms (typical)

AC reverse protection

Available

Maximum bypass overload current

30A

Inverter mode

Output voltage waveform

Pure sine wave

Rated output power (VA)

2000

3000

Rated output power (W)

2000

3000

Power factor

1

Rated output voltage (Vac)

230Vac

Output voltage error

±5%

Output frequency range (Hz)

50Hz ± 0.3Hz/60Hz ± 0.3Hz

Efficiency

>92%

Overload protection

(102% < load<125%) ±10%: report error and turn off the output after5 minutes; (125% < load < 150%) ± 10%: report error and turn off the output after 10 seconds; Load >150% ±10%: report error and turn off the

output after 5 seconds;

Peak power

4000

6000

Loaded motor capability

1HP

2HP

Output short circuit protection

Circuit breaker

Bypass breaker specifications

30A

Rated battery input voltage

24V (Minimum starting voltage 22V)

Battery voltage range

(20.0Vdc~33Vdc ± 0.6Vdc (Undervoltage alarm/shutdown voltage/overvoltage alarm /overvoltage recovery settable on LCD screen)

Power saving mode

AC charging

Load ≤25W

Battery type

Lead acid or lithium battery

Maximum charge current

60A

80A

Charge current error

± 5Adc

Charge voltage range

18.0Vdc~33Vdc

Short circuit protection

Circuit breaker and blown fuse

Circuit breaker specifications

30A

Overcharge protection

Alarm and turn off charging after 1 minute

PV charging

Maximum PV open circuit voltage

100Vdc

PV operating voltage range

30-100Vdc

MPPT voltage range

30-95Vdc

Battery voltage range

18-33Vdc

Maximum output power

1400W

PV charging current range (can be set)

0-60A

Charging short circuit protection

Blown fuse

Wiring protection

Certified specifications

Reverse polarity protection

Certification

CE(IEC/EN62109-1,-2)、ROHS2.0

EMC certification level

EN61000

Operating temperature range

-15°C to 55°C

Storage temperature range

-25°C ~ 60°C

Humidity range

5% to 95% (Conformal coating protection)

Noise

≤60dB

Heat dissipation

Forced air cooling, variable speed of fan

Communication interface

USB/RS485(Bluetooth/WiFi/GPRS)/Dry node control

Size (L*W*D)

378mm*280mm*103mm

Weight (kg)

6.2

Solar Panel 330W 20V Half Cell Black Frame

Brand Name ：Singfo Solar
Model NO.: SFM-330
Pmax(Peak Power):330W
Power Deviation:+-3%
Vmp(Peak Voltage ):33.9V
Imp(Peak Current ):10.03A
Voc(Open Circuit Voltage ):41.4V
Isc(Short Circuit Current):10.44A
Net Weight:18.5KG
Size:1685*992*35MM

Gel Battery 12v 100AH Free Maintanience

2 year of warranty

Certificate-CE
